Short Description:

Basic Info Model No.: JH-6550 Portable: Non Portable Form: Other Application: Security Check, Other Type: Conveying X-ray Detector Certification: CE, ISO Customized: Non-Customized Alarm Form: Audible Alarm Tunnel Size: 650(: Conveyor Speed: 0.22 M/s 1 Additional Info Packaging: paper carton Productivity: 100 pcs/month Brand: Anhushen Trans...


Product Detail

Product Tags


Basic Info

Model No.: JH-6550

Portable: Non Portable

Form: Other

Application: Security Check, Other

Type: Conveying X-ray Detector

Certification: CE, ISO

Customized: Non-Customized

Alarm Form: Audible Alarm

Tunnel Size: 650(: Conveyor Speed: 0.22 M/s 1


Additional Info

Packaging: paper carton

Productivity: 100 pcs/month

Brand: Anhushen

Transportation: Ocean,Land

Place of Origin: China

Supply Ability: 100 pcs/month

Certificate: CE,FCC

Port: Shenzhen


Product Description

X Ray Cargo Inspection System At6550

      That`s why people trust JH-6550 X-ray baggage scanner to complete all securityprotocols thoroughly and efficiently. The 650 mm *500 mm tunnel makes the X-Ray inspection system JH-6550 easy toscan small and medium parcels and bags, which also enhances the chances tocatch any suspicious items and overall security threats. There are more details of x-ray screening equipment as below.

Feature:

1.     Alarm by sounds & light: Alarm bysounds and light when conform to condition.

2.     Network interface: Could be connectlocal area network and support multi-terminal check baggage at same times

3.     Safety ray: Transmit ray under automaticcontrol, avoids the miss.

4.     Simple operation by mouse: Withoutkeyboard and work table, control by mouse, save space.

5.     Turn off by a key control: Turn off the x-ray security scanner only need one step: revolves the key. The x-ray parcel scanner automatic securityclose-down, does not need complex many steps, is simpler.

6.     Eagle-eye: Could be expedientlyobserving enlargement area.

7.     Estimate malfunction by self: Automaticestimate malfunction and prompt message, helpful for the maintenance



Technical data:

Tunnel Size:                       650(W)×500(H)mm

Conveyor Speed:                  0.22 m/s 1

Conveyor Max Load:             160 kg

Maximum single inspection dosage:       < 1.5µGy(adjustable)

Wire Resolution:                  0.1mm metal line

Steel Penetration:                38MM armor plate

Film Safety:                        For ISO 1600

Maximum leakage radiation:      <0.3µGY/H



X-ray generator:

Orientation:                                  Vertically Upward

Tube Current:                                0.4~1.2MA(adjustable)

Anode Voltage:                              100~160 KV(adjustable)

Angle:                                        80°

Generator cooling/working periods:     Sealed oil bath with forced air/100%



Image performancesystem:

X-ray sensor: l type photo-diode array detector, 12bit

Monitor: high resolution 17inch color LCD display

Color quality: 24 bit real colors

Edge enhancement: object contour edge is more distinct

Super image enhancement: image detail is more distinct

High penetrate strength display: increase brightness of darkarea in image to display object which is behind high absorbtivity massdistinctly

Low penetrate strength display: increase contrast of lowabsorbtivity mass (easy to penetrate) to display it distinctly

Magnifier: function of partial enlargement

Brightening/dimming: increase brightness of image/decreasebrightness of image

Image recurrence: display previous twenty images and processany one of them

Image restoration :restore image to initial status at thetime of stopping conveyor

Image storing: real time store any image and process it inoperation status



Multi-energyfunction:

Multi-energy color :display organic material for orange,display inorganic material for blue, and display mixture for green

High energy/low energy: switch to display two energy type,high energy stands for metal etc., low energy stands for nonmetallic

Auxiliary function for drugs & explosives: help todetect such dangerous material as drugs & explosives etc.

Audible & visible alarm: give sound and visible signal whenconforming to condition



Operatingenvironment:

Storage Temperature:             -20ºC to 60ºC

Operating Temperature:           0ºC to 45ºC

Relative Humidity:               20 to 95% non-condensing

System Power:                  220 VAC (±10%) 50±3HZ

Power wastage:                 1.0 KW (Max)

Noise:                         <65DB

X-Ray Inspection System At6550
